Coxreels 1125 Series Steel Hand Crank Hose Reel 100 Foot Hose Capacity, Blue
Product details
| Management number | 230695564 | Release Date | 2026/06/18 | List Price | $160.40 | Model Number | 230695564 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Coxreels 1125 Series hand crank hose reels have the features demanded by industry professionals. The industry preferred design features a sturdy one-piece all welded A-shaped frame base, low profile outlet riser, and open drum slot design provides a non-crimping, flat smooth hose wrap. The A-frame is a sturdy 1-piece, all CNC robotically welded 12 Gage steel base, not bolted, for superior reel structure. And the mounting pattern is located in the steel base for easy reel installation and detachment. Heavy-duty CNC robotically spun and ribbed discs with rolled edges for greater strength, durability, hose or electrical cord protection, and operator safety. The other features include long-lasting, chip resistant and rust inhibiting CPC powder coat finish, adjustable tension brake prevents freewheeling and front bevel geared crank for easy mechanical retraction. Please note that the garden hose is not included, but will hold up to 100 feet of 0.75-inch standard hoses.
- This retractable hand crank reel features a long-lasting nickel plated swivel inlet
- Steel spun discs with rolled edges for hose protection and operator safety
- Outlet and open drum slot design allows for a not-cimping smooth hose wrap
- One piece welded A frame base built to last a lifetime
- Permanently lubricated bearing on handle rod keeps reel spinning smoothly
- Long lasting steel construction ideal in commercial and industrial settings
- Intended hose size : 0.75 inches x 100 feet
- Max pressure: 3000 PSI
- Weight: 42 pounds
- Overall dimensions (L x H x W): 26.75 x 18.75 x 17.63 inches
- Base dimensions: 17.38 x 15.38 inches
- Manufacturer warranty: 2-year warranty
| Hose reel type | Hose Holder |
|---|---|
| Holding capacity | 100 ft |
| Features | mounting: floor, wall, bench and truck, swivel material: brass, max. pressure rating: 3000 psi, height:, not included: -, application: for lawn care, pest control, grounds maintenance, pressure washing, steam cleaning, spraying operations, washdown, fire protection, water discharge, can be mounted on stationary and mobile units., drive type: hand crank, finish: powder coated, hose outlet: 3/4" (m)npt, inlet size: 3/4" (f)npt, max. temp. rating: 275, seal type: buna n: nitrile, motor voltage: -, color: blue |
| Material | Steel |
| Brand | Coxreels |
| Color | Blue |
| Dimensions | 25.50 x 18.00 x 18.75 in |
| Weight | 41.85 |
| Model | 1125-5-100 |
| Pack quantity | 1 |
